| Part Number | Size |
| 80PVC088 | 3/4″ x 1/2″ |
| 80PVC089 | 1″ x 1/2″ |
| 80PVC090 | 1″ x 3/4″ |
| 80PVC091 | 1-1/4″ x 1/2″ |
| 80PVC092 | 1-1/4″ x 3/4″ |
| 80PVC093 | 1-1/4″ x 1″ |
| 80PVC094 | 1-1/2″ x 1/2″ |
| 80PVC095 | 1-1/2″ x 3/4″ |
| 80PVC096 | 1-1/2″ x 1″ |
| 80PVC097 | 1-1/2″ x 1-1/4″ |
| 80PVC098 | 2″ x 1/2″ |
| 80PVC099 | 2″ x 3/4″ |
| 80PVC100 | 2″ x 1″ |
| 80PVC101 | 2″ x 1-1/4″ |
| 80PVC102 | 2″ x 1-1/2″ |
Referential Standards
NSF/ANSI 61 Drinking Water System Components – Health Effects
NSF/ANSI 14 Plastics Piping System Components and RelatedMaterials
ASTM D 1784 Standard Specification for Rigid Poly(Vinyl Chloride)(PVC) Compounds and Chlorinated Poly(Vinyl Chloride) (CPVC)
CompoundsASTM D 2466 Standard Specification for Poly(Vinyl Chloride) (PVC)Plastic Pipe Fittings, Schedule 40
CSA B137.3 Rigid Polyvinylchloride (PVC) Pipe and Fittings forPressure Applications
